SVEN Pro+ 400
SVEN Pro+ 400
Short product description:
- Input voltage range: 165 – 275 V (built-in AVR)
- Output voltage range: 220 V ± 10 %
- Cold Start functiom in battery mode
- Load type: PC, monitor
SVEN Pro 400
SVEN Pro 600
SVEN Pro 650 (LCD, USB)
SVEN Pro 800
SVEN Pro 1000 (USB)
SVEN Pro 1500 (LCD, USB)
SVEN UP-L800
SVEN UP-L1000E
SVEN RT-500
SVEN RT-1000
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Input voltage range: 165 – 275 V (built-in AVR)
- Output voltage range: 220 V ± 10 %
- Cold Start functiom in battery mode
- Load type: PC, monitor
- Short-circuit protection, pulse and high-frequency disturbance protection
- Transformer thermal protection
- Non-flammable ABS plastic case
| UPS type | line-interactive |
| Total power, VА | 400 |
| Active power, W | 240 |
| Maximal output power, W | 240 |
| Type of load | computer, monitor |
| Input voltage level, V | ~165 – 275 |
| Output voltage level, V | ~220 ± 10 % |
| Output voltage waveform | approximated sinusoid |
| Input frequency, Hz | 50 |
| Output frequency, Hz | 50 ± 1 % (backup mode) |
| Input socket | 1 × СЕЕ7/7 |
| Output sockets | 1 × CEE7/4 |
| Protection | against short circuit, impulse and high frequency interferences; transformer thermal protection |
| Accumulator type | maintenance-free sealed lead-acid batteries (consumables) |
| Battery voltage, V | 12 |
| Battery capacity, А•h | 7 |
| Typical switching time, ms | ≤ 10 |
| Batteries operation time, min | 3-20 (dependent on connected load) |
| Indicators | power LED, on-line operation LED, charge LED |
| Fuse | cutout |
| Environmental temperature, °С | 0 – 40 |
| Relative humidity, % | 10 – 90 |
| Efficiency, % | 80 |
| Case material | ABS plastic |
| Dimensions (W × H × D), mm | 95 × 165 × 340 |
| Weight, kg | 4.4 |
| Color | black |
| Life time | 5 years |
Other items
News
SVEN VR-F600 AUTOMATIC VOLTAGE REGULATOR — FULL POWER SAFETY CONFIDENCE
SVEN automatic voltage regulators range is well known to users seeking for truly high-quality and reliable protection of electrical appliances as comfortable as possible and without excessive costs.
Details >>
SVEN SF-10E-16 EXTENSION SURGE PROTECTOR — SAFE CONNECTION OF UP TO TEN DEVICES
The main thing that is interesting about SVEN SF-10E-16 is, undoubtedly, the safe and convenient connection of up to 10 devices at once, and with a solid total power.
Details >>
SVEN MC-50 ACOUSTIC HI-FI SYSTEM — PEOPLE'S FLAGSHIP FROM THE LEGENDARY LINE
For decades, multimedia 2.0 acoustics from our company have enabled a wide range of music lovers to experience real Hi-Fi. Our speakers have always been appreciated not only for their good sound, but also for their affordable price.
Details >>SVEN Pro+ 400 line-interactive UPS is designed for protecting PCs, workstations and servers equipped with switched mode power supplies. Due to the built-in battery, the UPS can operate even in complete voltage blackout, which enables the user to save data and shut down the operating system correctly. The built-in AVR allows automatic voltage adjustment within 165–275 V and ensures long uninterrupted work. This feature is essential for networks with unstable voltage.
Sven Pro+ 400 is supplied with Cold Start function, allowing to force the UPS into operation in complete absence of mains voltage.
