SVEN Smart 1500
SVEN Smart 1500
Short product description:
- Sine output voltage both in on-line and off-line mode
- Wide range of input voltage
- High efficiency
- Built-in surge protector
SVEN Pro 400
SVEN Pro 600
SVEN Pro 650 (LCD, USB)
SVEN Pro 800
SVEN Pro 1000 (USB)
SVEN Pro 1500 (LCD, USB)
SVEN UP-L800
SVEN UP-L1000E
SVEN RT-500
SVEN RT-1000
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Sine output voltage both in on-line and off-line mode
- Wide range of input voltage
- High efficiency
- Built-in surge protector
- LCD display
- Indication of parameters and basic operation modes
- Sound alarm for off-line operation, overload and critical discharge level of storage batteries
- USB and RJ-11/RJ-45 communication ports
- Cold Start function in off-line mode
- Automatic electricity delivery at power supply renewal
- Short circuit and overload protection, pulse and high-frequency disturbance protection
- Modem/telephone circuit protection
| Maximum load, VA/W | 1500/900 |
| Input voltage level, V | 165 – 275 |
| Output voltage level, V | 220 ±10 % (on-line) 220 ± 5 % (via converter) |
| Output voltage waveform | sine wave (on-line and off-line) |
| Frequency, Hz | 50 |
| Communication port | USB, RJ-11/RJ-45 |
| Input terminals | CEE 7/4 |
| Output sockets | 2 × CEE 7/4 |
| Protection | hort circuit and overload modem/telephone circuit |
| Accumulator type | maintenance-free sealed lead-acid batteries (consumables) |
| Accumulators capacity | 12 V 9 А•h (2 pcs) |
| Typical switching time, ms | > 8 |
| Batteries operation time, min | 3-10 min. (depending on the load) |
| Indicators | variables and basic operation modes |
| Processor | RISC-microprocessor based |
| Controlled variable | current input and output voltage, frequency, battery charge level, load condition |
| Environment operation conditions | <5000 m above sea level, 0-50 °C, moisture 0 - 90% without condensation |
| Supported interfaces | intelligent software support of Windows 98/Mе/NT/2000/XP/2003/Vista, Linux, FreeBSD, Novell Netware |
| Certificates | UL. cUL, FCC, [CE,TUV] РосТест |
| Floating time | 4 hours (up to >85 %), 10 hours max (up to >90 %) |
| Dimensions (W × H × D), mm | 145 × 245 × 355 |
| Weight, kg | 13.9 |
| Life time | 5 years |
Other items
News
SVEN VR-F1200U AND VR-F2000U VOLTAGE STABILIZERS — UNIVERSAL PROTECTION AND CONVENIENT CHARGING
We are pleased to present a new line of single-phase relay voltage stabilizers designed for comprehensive protection of home appliances and simultaneous charging of mobile devices.
Details >>
SVEN PS-130 PORTABLE SPEAKER — WHERE MOOD COMES ALIVE
SVEN PS-130 portable speaker is more than just a compact audio device — it's a true mood maker that fits in the palm of your hand yet delivers sound far beyond its size. Weighing just half a kilogram and wrapped in an elegant body available in three vibrant colors — black, blue, or red.
Details >>
SVEN MC-15 HI-FI SPEAKER SYSTEM — HIGH-QUALITY SOUND IN THE SOUND STUDIO, LIVING ROOM, GAME ROOM
We are expanding the range of Hi-Fi products of MC series — introducing the new SVEN MC-15 multimedia 2.0 speaker system, an elegant combination of advanced technology and thoughtful design made for those who appreciate authentic sound quality.
Details >>SVEN SMART 1000/1500> line-interactive uninterruptible power supplies featuring sine output voltage are ideal equipment for protecting PCs and peripherals: monitors, modems, etc.
In case of electricity failure, the UPS continues supplying power to the consuming devices using the energy of the integrated storage batteries. The built-in AVR provides proper power supply to the load at over-/undervoltage without entering the off-line mode.
The UPS is designed for computer equipment only. Don't connect household heating appliances, other high-power electric devices and office equipment (room heaters, electric kettles, laser printers, air conditioners, etc.). These appliances increase power consumption considerably, and this can cause the UPS overload and breakdown.
Locate the UPS indoors only, in rooms with controlled air temperature and humidity. During operation, the housing of the device can heat up to 50°C, which is absolutely normal.
