SVEN SV645

UPS battery 6V 4,5Ah

Catalog Electrical Equipment Batteries SVEN SV645

AN: SV-0222064

SVEN SV645

UPS battery 6V 4,5Ah

Short product description:

Lead-acid AGM type storage battery
Leak-proof design
Doesn't require maintenance and service
Safe system of internal pressure control valves

All features

Similar products

SVEN SV1250

SVEN SV1270

SVEN SV1272

SVEN SV1290

SVEN SV12120

SVEN SV12170

SVEN SV121000

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Lead-acid battery of AGM type
Leak-proof design
Maintenance-free: doesn't require maintenance and can operate in any position
Design of interelectrode separators made of glass fiber increases service life
Does not liberate gas during operation
Valve system protecting the battery against increased pressure
Highly effective lead-calcium electrode grids increasing capacity
Lowered self-discharge current

Battery type	Lead-acid AGM type storage battery
Rated voltage, V	6
Maximum discharge current, A	67
Capacity (20 hours discharge), А • h	4.5
Maximum charging current, A	1.35
Internal resistance, MOhm	21
Self-discharge (at 25 °C of initial capacity) during the year	up to 36 %
Rated operating temperature, °C	25
Operating temperature range, °C	-20 up to +50
Terminal type	F1
Length, mm	70
Width, mm	48
Hight, mm	101
Total hight, mm	106
Weight, kg	0.7
Color	black
Life time	5 years

Other items

SVEN VR-F1000

Relay automatic voltage regulator, 320 W, 4 sockets

SVEN SPS-702

Speakers with volume and tone controls and headphone output on the front panel

SVEN SPS-580

230V speakers with headphone and microphone jacks

SVEN PS-770

Party speaker system with Bluetooth, karaoke and FM radio

SVEN AP-B800MV

Hybrid Active Noise Canceling (Hybrid ANC) wireless stereo headset

SVEN KB-C7500EL

Backlit wired keyboard

SVEN 450

Gaming mini soundbar for computer with Bluetooth and dynamic switchable lighting

SVEN PS-880

Portable speaker with Bluetooth, karaoke, FM radio and RGB backlight

SVEN KB-G9200

Mechanical backlit gaming keyboard

SVEN AVR SLIM-500 LCD

Relay automatic voltage regulator, wall-mounted, LCD, 400 W, 1 socket

SVEN PS-850

Party speaker system with Bluetooth, karaoke and FM radio

SVEN PS-1050

Party speaker system with Bluetooth, karaoke and FM radio

As of today the lead-acid maintenance-free batteries of AGM type are the most widespread type of batteries for the reserve power supply. The main fields of application are UPS; light, alarm and security systems; direct-current power supply; automatic control system.

Batteries of SVEN SV series are notable for the following specifications: low self-discharge current, wide operation temperature range, high coefficient of efficiency and quality of manufacture.
