SVEN Reserve Home-800
SVEN Reserve Home-800
Short product description:
- Continuous action with prolonged back-up time
- Regular sinusoidal output signal
- Microprocessor control
- Intellectual charger for connected external batteries (stora...
SVEN PS-1250
SVEN PS-1050
SVEN PS-1900
SVEN PS-1500
SVEN PS-1000
SVEN PS-950
SVEN PS-930
SVEN PS-860
SVEN PS-850
SVEN PS-800
SVEN PS-770
SVEN PS-750
SVEN PS-740
SVEN PS-730
SVEN PS-720
SVEN PS-710
SVEN PS-680
SVEN PS-670
SVEN PS-655
SVEN PS-650
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Continuous action with prolonged back-up time
- Regular sinusoidal output signal
- Microprocessor control
- Intellectual charger for connected external batteries (storage batteries) with the “training” mode of batteries
- Protection against short circuit, overvoltage or undervoltage of the mains and overload
- IP-20 ingress protection
- Self-diagnosis after switching on
- Indication of operation modes on LCD display
- Mode switchover time ≤ 5 msec
- Built-in line regulator
- Automatic start function
- Low noise level
| UPS type | line-interactive of continuous action with long backup time |
| Built-in AVR | available |
| Total power, VА | 800 |
| Active power, W | 480 |
| Type of load | household and industrial equipment |
| Maximum load, W | 480 |
| Input voltage level, V | ~150 – 275 |
| Output voltage level, V | ~220 ± 10 % |
| Output voltage waveform | regular sinusoidal signal |
| Input frequency, Hz | 50 |
| Output frequency, Hz | 50 |
| Number of phases | 1 |
| Input terminals | terminals for battery connection |
| Input socket | 1 × CEE 7/7 |
| Output sockets | 2 × CEE 7/4 |
| Allowable overload of the rated power, % | ≤ 110 |
| Overload protection acting, % | 120 |
| Protection | against high/low voltage, overload, short circuit and overvoltage |
| Beeps | low battery charge, overload, error |
| Accumulator type | maintenance-free sealed lead-acid batteries (not included) |
| Typical switching time, ms | < 5 |
| Cooling type | convective; by fan |
| Indication | operation modes on LCD display |
| Operation mode | continuous action with long backup time |
| Noise level, dB | 45 |
| Environmental temperature, °С | from -5 to +40 |
| Operating humidity, % | 10-90, without condensation |
| Efficiency, % | 65 |
| Case material | metal |
| Dimensions (W × H × D), mm | 140 × 214 × 367 |
| Weight, kg | 7.3 |
| Color | black |
| Life time | 5 years |
Other items
News
SVEN VR-F1200U AND VR-F2000U VOLTAGE STABILIZERS — UNIVERSAL PROTECTION AND CONVENIENT CHARGING
We are pleased to present a new line of single-phase relay voltage stabilizers designed for comprehensive protection of home appliances and simultaneous charging of mobile devices.
Details >>
SVEN PS-130 PORTABLE SPEAKER — WHERE MOOD COMES ALIVE
SVEN PS-130 portable speaker is more than just a compact audio device — it's a true mood maker that fits in the palm of your hand yet delivers sound far beyond its size. Weighing just half a kilogram and wrapped in an elegant body available in three vibrant colors — black, blue, or red.
Details >>
SVEN MC-15 HI-FI SPEAKER SYSTEM — HIGH-QUALITY SOUND IN THE SOUND STUDIO, LIVING ROOM, GAME ROOM
We are expanding the range of Hi-Fi products of MC series — introducing the new SVEN MC-15 multimedia 2.0 speaker system, an elegant combination of advanced technology and thoughtful design made for those who appreciate authentic sound quality.
Details >>SVEN RESERVE HOME uninterrupted power supplies developed and produced by SVEN Company are the ideal solution for the uninterrupted power supply for heating systems, intellectual fire-control units and security systems, automation and refrigeration systems, etc. in conditions of low quality level of power supply or in case of its complete absence.
They are designed for equipment, which is critical to the input current form: gas boilers, refrigeration equipment, devices with electric motors, compressors, transformers, etc., where UPS with clear output sinusoid is required.
SVEN RESERVE HOME line-interactive uninterrupted power supplies with a proper sinusoid in combination with batteries SVEN SV12500 and SVEN SV121000 are the optimal and universal choice to create the uninterrupted power supply system based on the price, consumer properties, coefficient of efficiency and battery service life.
Notice! Batteries are not included.
