SVEN Pоwer Pro+ 500
SVEN Pоwer Pro+ 500
Short product description:
- Digital microprocessor control
- Overload capability up to 140% of nominal power without load...
- High efficiency
- Wide range of auto regulation — AVR
...
SVEN Pro 400
SVEN Pro 600
SVEN Pro 650 (LCD, USB)
SVEN Pro 800
SVEN Pro 1000 (USB)
SVEN Pro 1500 (LCD, USB)
SVEN UP-L800
SVEN UP-L1000E
SVEN RT-500
SVEN RT-1000
-
FEATURES
-
SPECIFICATIONS
-
DESCRIPTION
-
UNBOXING VIDEO
-
SUPPORT
- Digital microprocessor control
- Overload capability up to 140% of nominal power without load switch-off
- High efficiency
- Wide range of auto regulation — AVR
- Built-in surge protector
- USB communication port
- Cold Start function (at DC power supply)
- Automatic power delivery mode after power supply renewal
- Built-in energy saving function: after entering offline mode, if the computer is off, the UPS switches off in 1 minute
- Short-circuit and overload protection
- Metal case
| Maximum load, VA/W | 500/320 |
| Input voltage level, V | 145-285 |
| Output voltage level, V | 198-242 (off-line), 198-242 (on-line) |
| Output voltage waveform | sine wave (on-line), step-approximate sine wave (off-line) |
| Frequency, Hz | 50 |
| Communication port | USB |
| Output sockets | EURO socket |
| Protection | from short circuit, overload, voltage surges, falls, brownouts, blackouts. Modem / telephone circuit protection |
| Alarm signals | beeps < 30 dB at a distance of 1 meter |
| Accumulator type | maintenance-free sealed lead-acid batteries (consumables) |
| Battery voltage, V | 12 |
| Batteries capacity, А • h | 7 |
| Typical switching time, ms | 5 |
| Batteries operation time, min | 3.6/12 (at full/half loading) |
| Indicators | on-line operation, battery operation, battery charge mode |
| Processor | RISC-microprocessor based |
| Controlled variable | current input and output voltage, connected load level |
| Environment operation conditions | 0-40 °C, moisture 0-90 %, without condensation |
| Supported interfaces | intelligent software support of Win9X/Mе/NT/2000/XP/Vista/7 |
| Certificates | UL. cUL, FCC, [CE,TUV] РосТест |
| Floating time | 4 hours (up to >85 %), 8 hours max (up to >90 %) |
| Dimensions (W × H × D), mm | 330 × 88 × 140 |
| Weight, kg | 4.45 |
| Life time | 5 years |
Other items
Multifunctional speaker system with Bluetooth, USB/SD player, FM radio, display, remote control
Nominal power of SVEN Power Pro+ 500 UPS is 500 VA/300 W.
SVEN Power Pro+ 500 is a reliable budget-priced device made under line-interactive UPS technology and designed for protection of home and office computer equipment not allowing power breakdowns. The UPS provides protection of PCs and the connected peripherals from high voltage pulses and induced interferences.
SVEN Power Pro+ 500 is produced in a metal case and has a euro socket. Due to technical solutions applied, the device is characterised with high overload capacity ensuring the operation of the equipment in conditions of short- or long-time overloads. Passive ventilation allows noiseless operation.
Designed for protecting PCs, workstations, network and commutation equipment, various telecommunication and other office and computer equipment.
